Key Features and Benefits
- Powerful Performance: Designed with high airflow capacity for effective and efficient ventilation.
- Durable Construction: Engineered to withstand demanding industrial environments with rugged materials.
- Energy-Efficient Design: Operates with low energy consumption for cost-effective performance.
- Versatile Mounting Options: Can be mounted on roofs or floors for flexible installation.
- Wide Range of Applications: Suitable for a variety of industrial and commercial settings
Specifications
| Blade Diameter (mm) | Outer Diameter (mm) | Air Flow (CFM) | Motor Rating (HP) | Supply Voltage (V) | Phase | Frequency (Hz) | Max Current (A) | Rotating Speed (RPM) | Noise Level (dB) |
|---|---|---|---|---|---|---|---|---|---|
| 1000 | 1080 | 18000 | 1.5 | 400 | 3 | 50 | 2 | 550 | 46 |
| 1300 | 1380 | 20000 | 2 | 400 | 3 | 50 | 3.2 | 550 | 50 |
| 1800 | 1880 | 35000 | 2 | 400 | 3 | 50 | 4.5 | 400 | 50 |
